Split AC EH0B Error Code Fix – Step-by-Step Troubleshooting Guide

Split AC EH0B Error Code Fix – Step-by-Step Troubleshooting Guide

EH0B Error Code ka matlab hota hai ki Outdoor Unit aur Indoor Unit ke beech communication problem, Outdoor PCB fault, ya Power Supply issue detect hua hai. Is error ki wajah se compressor start nahi hota aur AC cooling band ho jaati hai.

Step 1: Safety First

✅ MCB ko OFF karein.
✅ Outdoor aur Indoor Unit ki power supply disconnect karein.
✅ Multimeter aur PPE (Safety Gloves, Safety Shoes) ka use karein.

Step 2: Power Supply Check Karein

Indoor Unit

  • Input Voltage check karein.
  • 220–240 VAC milna chahiye.

Outdoor Unit

  • Outdoor terminal par bhi 220–240 VAC confirm karein.
  • Agar voltage nahi aa raha hai to wiring ya MCB check karein.

Step 3: Interconnecting Wiring Check Karein

Indoor se Outdoor jaane wali wiring ko check karein.

✔ Loose Terminal
✔ Reverse Wiring
✔ Burnt Wire
✔ Open Circuit
✔ Short Circuit

Multimeter se continuity check karein.

Step 4: Communication Voltage Check Karein

Communication Terminal par DC Voltage measure karein.

  • Voltage fluctuate hona chahiye.
  • Agar communication signal nahi mil raha hai to PCB ya communication line faulty ho sakti hai.

Step 5: Outdoor PCB Inspection

Outdoor PCB ko visually inspect karein.

Check karein:

  • Burn Mark
  • Carbon
  • Water Damage
  • Rust
  • Loose Connector
  • Swollen Capacitor

Agar PCB physically damaged hai to repair ya replace karein.

Step 6: Indoor PCB Check Karein

Indoor PCB par

✔ 5V DC
✔ 12V DC
✔ Communication IC

check karein.

Agar required voltages missing hain to Indoor PCB faulty ho sakta hai.

Step 7: Compressor aur Fan Connection Check Karein

Outdoor PCB se

  • Compressor Connector
  • Fan Motor Connector
  • Reactor Connection

sab properly connected hone chahiye.

Step 8: Sensor Check Karein

Outdoor Sensors

  • Coil Sensor
  • Ambient Sensor
  • Discharge Sensor

Resistance manufacturer chart ke according honi chahiye.

Step 9: Earthing Check Karein

Poor Earthing bhi communication issue create kar sakti hai.

Earth Resistance standard limit ke andar honi chahiye.

Step 10: PCB Reset Karein

Power OFF karein.

5 Minute wait karein.

Power ON karke error dobara check karein.

Step 11: Error History Check Karein

Agar AC service mode support karta hai to

  • Error History
  • Last Fault
  • Current Fault

check karein.

Step 12: Test Run Karein

AC ko Cooling Mode par chalayein.

Observe karein:

✅ Compressor Start ho raha hai?

✅ Outdoor Fan chal raha hai?

✅ Communication Stable hai?

✅ Error dobara aa raha hai ya nahi?

Possible Causes of EH0B Error

  • Outdoor PCB Fault
  • Indoor PCB Fault
  • Communication Wire Open
  • Communication Wire Reverse
  • Loose Terminal Connection
  • Low Input Voltage
  • High Input Voltage
  • Power Supply Failure
  • Damaged Communication Circuit
  • Water-Damaged PCB
  • Defective Sensor
  • Poor Earthing

Required Tools

  • Digital Multimeter
  • Clamp Meter
  • Screwdriver Set
  • Insulation Tester (Megger)
  • Continuity Tester
  • PCB Tester (if available)

Pro Technician Tip

✔ Kisi bhi PCB ko replace karne se pehle power supply, wiring aur communication line ko zaroor verify karein. Bahut baar EH0B Error sirf loose terminal, incorrect wiring ya voltage issue ki wajah se aata hai, aur bina wajah PCB replace karne se customer ka unnecessary cost badh sakta hai.

What is the EH0B Error Code?

The EH0B Error Code generally indicates a communication failure between the Indoor Unit and Outdoor Unit, an Outdoor PCB fault, or a power supply issue. When this error occurs, the compressor will not start, and the air conditioner will stop cooling.

Step 1: Safety First

  • Turn OFF the MCB (Main Circuit Breaker).
  • Disconnect the power supply to both the Indoor and Outdoor Units.
  • Wear appropriate PPE (Safety Gloves, Safety Shoes) and use a digital multimeter.

Step 2: Check the Power Supply

Indoor Unit

  • Measure the input voltage.
  • Ensure the supply voltage is 220–240 VAC.

Outdoor Unit

  • Verify that 220–240 VAC is also available at the outdoor unit terminals.
  • If voltage is missing, inspect the MCB, wiring, and electrical connections.

Step 3: Inspect the Interconnecting Wiring

Check the cable connecting the Indoor and Outdoor Units for:

  • Loose terminal connections
  • Incorrect or reversed wiring
  • Burnt or damaged wires
  • Open circuit
  • Short circuit

Use a multimeter to verify continuity.

Step 4: Check the Communication Signal

Measure the communication voltage at the communication terminal.

  • The communication signal should fluctuate during operation.
  • If there is no communication signal, inspect the communication wiring and PCB.

Step 5: Inspect the Outdoor PCB

Perform a visual inspection of the Outdoor PCB for:

  • Burn marks
  • Carbon deposits
  • Water damage
  • Rust or corrosion
  • Loose connectors
  • Swollen or damaged capacitors

Repair or replace the PCB if any physical damage is found.

Step 6: Check the Indoor PCB

Verify the following supply voltages on the Indoor PCB:

  • 5 VDC
  • 12 VDC

Also inspect the communication circuit and IC components.

If the required voltages are missing, the Indoor PCB may be faulty.

Step 7: Check Compressor and Fan Connections

Inspect all Outdoor PCB connections, including:

  • Compressor connector
  • Outdoor fan motor connector
  • Reactor connection

Ensure all connectors are properly seated and secure.

Step 8: Check the Sensors

Test the Outdoor Unit sensors:

  • Coil Temperature Sensor
  • Ambient Temperature Sensor
  • Discharge Temperature Sensor

Measure the sensor resistance and compare it with the manufacturer's specifications.

Step 9: Check Earthing

Poor grounding can also cause communication problems.

Ensure the earth connection is secure and the earth resistance is within the recommended limit.

Step 10: Reset the System

  • Turn OFF the power supply.
  • Wait for approximately 5 minutes.
  • Restore power and check whether the error has cleared.

Step 11: Check Error History

If the air conditioner supports service mode, review:

  • Error history
  • Previous fault records
  • Current fault status

This can help identify intermittent or recurring issues.

Step 12: Perform a Test Run

Operate the air conditioner in Cooling Mode and verify:

  • Compressor starts normally
  • Outdoor fan operates correctly
  • Communication remains stable
  • The EH0B error does not reappear

Possible Causes of EH0B Error

  • Outdoor PCB failure
  • Indoor PCB failure
  • Open communication wire
  • Reversed communication wiring
  • Loose terminal connection
  • Low input voltage
  • High input voltage
  • Power supply failure
  • Faulty communication circuit
  • Water-damaged PCB
  • Defective temperature sensor
  • Poor earthing/grounding

Required Tools

  • Digital Multimeter
  • Clamp Meter
  • Screwdriver Set
  • Insulation Resistance Tester (Megger)
  • Continuity Tester
  • PCB Tester (if available)

Professional Technician Tip

Before replacing any PCB, always verify the power supply, communication wiring, terminal connections, and grounding. In many cases, the EH0B error is caused by loose connections, incorrect wiring, or unstable voltage, and replacing the PCB without proper diagnosis can result in unnecessary repair costs for the customer.
